Trigger ActionRange: Airmovers:
Group: Trigger Action Blow Guns
Product: CG22DH

Technical details.

<< Back

Material: Nylon
Weight: 0.20Kg
Standard Gap: Adjustable
DBA at: 5.5 bar is 79
Optional Extra
Standard Inlet Threads: 1/4" BSP
Options: 1/4 NTP
Please specify on order 1/4" NPTF

Bar Vol in m³ /min Vol out m³ /min
1.38 0.185 1.344
2.76 0.304 2.016
4.14 0.421 2.52
5.52 0.531 2.94






cg22dh
